Flanged Inline Air Heating System
An Optimized Solution For Aerospace Industry
Safe, precise, and durable performance.
Growing global demand for fuel efficiency, reduced emissions, and renewable energy has given rise to research into new technologies dependent on ever increasing temperature and pressure gas streams. Tutco SureHeat's Specialty Flanged Inline (SFI) Heaters deliver safe, precise, and durable performance in a wide range of extremely demanding applications. Even our “Standard” products offer extreme levels of performance, while our “custom” models push the limits of technology.
Key Advantages:
Specialty Flanged Inline (SFI) inline heaters offer superior performance over conventional sheathed (“tubular” or “immersion”) style heaters because they are designed specifically for air and inert gas applications.
Tutco SureHeat’s proprietary SERPENTINE element facilitates a very high power density and compact overall design. SFI heaters can be as much as 8-12X smaller than equivalent tubular/immersion designs.
With this advantage, installations become smaller, lighter, and more cost effective, with a faster heat-up and cool-down time.
Whether for a research test stand, factory production line, or key component in a product or system, Tutco SureHeat’s Specialty Flanged Inline heater is the right tool for the job.
Typical Applications:
- Combustion research
- Turbine cooling research
- Core engine test
- Wind tunnel
- Bleeding air system research
- Enviroment control system research
- Valve testing for aviation maintenance, repair, and overhaul (MRO) facilities.
Features:
- Achieve temperatures up to 1500°F (815°C) and 1650°F (900°C) in custom design.
- Controllability +/- 2°F (+/-1°C)
- Rapid temperature ramp, up to 50°C per second in custom designs.
- Power ratings in single heaters 18kW to 768kW Standard, 1 MW and higher in custom design.
- Pressure Ratings up to 600 PSI (40 Bar) standard, >3000 PSI (207 Bar) in custom design.
- Pressure vessels per ASME Section VIII Div. 1, certification services and documentation available upon request.
- Pressure Equipment Directive (PED) certification is available for European customers.
- ANSI and DIN flange sizes available.
- SCR power and temperature control cabinets.
- On-site start-up assistance and training available.
- RoHS compliant.
- Replaceable element cartridge.
